611G

SKU: 611G

The 611G Series is an economical, compact sized, all aluminum gage pressure switch. It is modeled after our flagship 6900 Series with the same level of performance and quality but designed for applications where space and cost are a concern. It has high vibration and shock resistance utilizing Dual Snap® disc spring technology. Applications include nonhazardous environments such as:

• Power Generation
• Rail Car
• Fluid Management
• Manufacturing Process
• Utilities, Water Treatment and Waste
• Chemical Refining and Processing
• Heavy Vehicles
• Safety Systems

Description

The 611G Series is an economical, compact pressure switch. It is modeled after our flagship 6900 Series with the same level of performance and quality but designed for applications where space and cost are a concern. Made from aluminum, it has high vibration and shock resistance utilizing Dual Snap® disc spring technology. Applications include nonhazardous environments such as:

• Power Generation
• Rail Car
• Fluid Management
• Manufacturing Process
• Utilities, Water Treatment and Waste
• Chemical Refining and Processing
• Heavy Vehicles
• Safety Systems

Additional information

Environmental Approvals	IP65, NEMA 4, NEMA 13, RoHS
Industry	Industrial
Instrumentation	Pressure Switch
Environment	Non-Hazardous
Certification Agency Approvals	CE, CRN
Operating Temperature Range	-40° to 186 °F
Process Connection Fitting Size	Male 1/4" NPT
Process Connection Material	Aluminum
Housing Enclosure	Aluminum
Electrical Connection	Male 1/2" NPT
Electrical Switch Type	SPDT
Voltage Electrical Rating VAC	0 to 250 VAC
Amperes Electrical Rating	0.5 to 11 A
Junction box app	141-18, 141-19, 141-20, 141-28
Fixed or Adjustable Set Point	Adjustable, Fixed
Presetting	Factory Set, Not Factory Set
Tagging	Mylar, Stainless Steel
Accessories	Manifold
Increasing Pressure Range	1.5 to 12.1 PSIG, 1.5 to 25 PSIG, 12.1 to 30 PSIG, 26 to 80 PSIG, 30.1 to 70 PSIG, 70.1 to 180 PSIG, 81 to 180 PSIG
Decreasing Pressure Range	0.75 to 11.35 PSIG, 1 to 23 PSIG, 10.1 to 28 PSIG, 23 to 73.5 PSIG, 27.1 to 67 PSIG, 63.1 to 173 PSIG, 66 to 153 PSIG
Pressure Type	Gage
Media	Oil Based, Non-Oil Based
Increasing Pressure Ranges	1.16 – 2.99 PSI, 3 – 180 PSI
Decreasing Pressure Ranges	0 – 1.15 PSI, 1.16 – 173 PSI
Maximum System Pressure	250, 500
Maximum Proof Pressure	500, 1000
Process Connection Seal	O-Ring Sealed Diaphragm
Diaphragm	Polyimide
O-ring	Buna N
